SKFFBSA 210 A/ QFC參數
| 角接觸推力球軸承 for screw drives, cartridge units with flanged housing | |||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 預壓 | SKF | SNFA | |||||||
| A | B | ||||||||||
| d | D2 | A | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 50 | 128 | 106 | 75,795 | 292 | 10,8 | 3000 | 1500 | 9,3 | FBSA 210 A/ QFC | BSQU 250/1 TFT | |
SKFAngular contact thrust ball bearings for screw drivesFBSA 210 A/ QFC屬于超高精密軸承，它是角接觸推力球軸承 for screw drives, cartridge units with flanged housing的Angular contact thrust ball bearings for screw drives，內徑：50，外徑：128，厚度106，SKFFBSA 210 A/ QFC主要應用于減速裝置、等領域。如果您需要購買或者了解更多關于SKFFBSA 210 A/ QFC的信息， 歡迎撥打訂購熱線：022-27921004
- SKFFBSA 210 A/ QFC近似型號
- SKF CR 21048 尺寸：54mm × 66 × 8 類型：徑向軸密封件 備注：徑向軸密封件
- SKF 6210/HR11QN 尺寸：50mm × 90 × 20 類型：工程產品 備注：聚合物球軸承,單列球軸承
- SKF NU 210 ECJ * 尺寸：50mm × 90 × 20 類型：圓柱滾子軸承 備注：單列
- SKF 210-2Z 尺寸：50mm × 90 × 20 類型：深溝球軸承 備注：單列，帶裝球缺口
- SKF YAT 210 尺寸：50mm × 90 × 38.8 類型：Y-軸承 備注：帶平頭螺釘鎖定的
- SKF 6210-2Z/VA208 尺寸：50mm × 90 × 20 類型：深溝球軸承 備注：用于高溫的深溝球軸承
- SKF 6210/HR22T2 尺寸：50mm × 90 × 20 類型：工程產品 備注：聚合物球軸承,單列球軸承
- SKF 2 x 7210 BECBJ 尺寸：50mm × 90 × 40 類型：角接觸球軸承 備注：單列，用于配對安裝
- SKF NUP 2210 ECP * 尺寸：50mm × 90 × 23 類型：圓柱滾子軸承 備注：單列
- SKF CR 180X210X15 HMSA10 RG 尺寸：180mm × 210 × 15 類型：徑向軸密封件 備注：徑向軸密封件
- SKFFBSA 210 A/ QFC相關型號
- SKFFBSA 208/ DB 尺寸：40mm × 124 × 66 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 207/ QFC 尺寸：35mm × 90 × 86 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 205/ QFC 尺寸：25mm × 80 × 82 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 205/ DB 尺寸：25mm × 80 × 52 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 208 A/ QFC 尺寸：40mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 212 A/ QBC 尺寸：60mm × 145 × 114 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 205/ DF 尺寸：25mm × 80 × 52 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 204/ QFC 尺寸：20mm × 60 × 77 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 204/ QBC 尺寸：20mm × 60 × 77 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210 A/ QBC 尺寸：50mm × 128 × 106 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
- SKFFBSA 210 A/ QFC推薦型號
- FAFNIR 6252 尺寸：260mm × 480 × 80 類型：
- SNR 6307-Z 尺寸：35mm × 80 × 21 類型：
- MRC 6214-2RS 尺寸：70mm × 125 × 24 類型：
- SKF 7317B 尺寸：85mm × 180 × 41 類型：
- KOYO 7312B 尺寸：60mm × 130 × 31 類型：
- SKF 71928C/DB 尺寸：140mm × 190 × 48 類型：
- KOYO 7221AC/DB 尺寸：105mm × 190 × 72 類型：
- ZKL 7312B/DB 尺寸：60mm × 130 × 62 類型：
- GMN 7004AC/DT 尺寸：20mm × 42 × 24 類型：
- RHP 51218 尺寸：90mm × 135 × 35 類型：
